Product Details
Place of Origin: Jiangsu, China (Mainland)
Brand Name: JIUQI
Certification: RoHS,ISO9001
Model Number: 25BYZ-33
Payment & Shipping Terms
Minimum Order Quantity: 100PCS
Price: $15~$35/PCS
Packaging Details: with export carton . Bulk order with pallets
Delivery Time: Trial orders :2 WEEKS Bulk orders: within 3 weeks
Payment Terms: T/T, Western Union,paypal
Supply Ability: 200000 PCS/MONTH
Push Force: |
200/100/300 |
Screw Distance: |
1/5/2MM |
Rate Current: |
1.4A |
Motor Length: |
31/60MM |
TYPE: |
STEPPER MOTOR |
PRODUCT NAME: |
LINEAR MOTOR |
Push Force: |
200/100/300 |
Screw Distance: |
1/5/2MM |
Rate Current: |
1.4A |
Motor Length: |
31/60MM |
TYPE: |
STEPPER MOTOR |
PRODUCT NAME: |
LINEAR MOTOR |
hint:
1. The current should be set on the driver during use. If the current exceeds 10% of the
rated current for a long time, the motor may be burned out, please pay attention!
2. The pulse sent by the controller should meet the needs of the driver
3. If you use our controller and driver, please refer to the manual of the controller and driver
2. Specification
| Model no. | Push force(W) |
Screw pitch (MM) |
Feed speed (MM/S) |
Resolution (MM/Step) |
Rated current (A) |
Weight (KG) |
Motor length(MM) |
| LHB4231A1404-6x1 | 200 | 1 | 50 | 0.005 | 1.4 | 0.2 | 31 |
| LHB4231A1404-5X5 | 100 | 5 | 250 | 0.025 | 1.4 | 0.2 | 31 |
| LHB4260A1804-6X2 | 300 | 2 | 100 | 0.01 | 1.8 | 0.5 | 60 |
3. Mechanical Dimension:MM
4. Typical Applications
· Medical Equipment
· Automatic Control
· 3D Printer
· Precision Calibration
· Precise Position Movement
5. Terms of trade
| Terms of price | FOB,CIF,CFR,EXW,DDP,etc. |
| Terms of payment | 100% T/T in advance for samples |
| Bulk quantity payment way can be negotited | |
| Warranty | 12 months limited warranty once the items are delivered to the buyer. |
| Lead time | Usually within 2 weeks for trial orders, within 3 weeks for bulk orders. |
| Package | Cartons /Pallets |
| Place of loading | Shanghai, Ningbo, etc. |
| Delivery time | Usually within 5 working days by Express 15-30 working days by vessel |
6. Shipping
7.Payment
